Who We Are
XHT is an All-in-One solution provider for the fabrication of high reliability, multi-layer, complex boards. Our PCBA services include supply chain management, assembly, test & inspection, rework, and NPI (New Product Introduction). The combination of our experience since 2004 in PCB & PCBA provision serves as a solid base for miniaturization solutions, which include organic substrates and advanced packaging.
What We Do
Our highly experienced team, state-of-the-art technologies, and advanced processes enable us to deliver innovative and complete solutions. All this while ensuring cost-effectiveness in a global network supply chain. A can-do attitude and a heterogeneous engineering approach are how we operate. This makes manufacturers’ reliance on multi-vendor operations redundant. Our common design rules throughout the design and fabrication stages minimize the need for compromise on off-the-shelf products, allowing us to develop innovative ones instead.
On-time delivery
Meet all order requirements from Prototypes to volumes
ON TIME, EVERY TIME.
Quality assurance
Comply with ISO, IATF, UL standards, Online SPI, AOI, X-Ray inspection equipment, 99.5% pass rate of product delivery.
Professional team
Expert Stackup team and 40+ High precision CAM editor team. We are not only experienced but highly qualified.
Quick Response Service
We will respond to your enquiries and share the quotation within 12 hours.
Technical Specification For PCB | Number of Layer | 1-58 Layers |
| Order Quantity | 5 to 100,000 Pieces per Month |
| Board Shape | Retangular,round,slots,cutouts,complex,irregular |
| Board Type | Rigid, Flexible, Rigid-flexible |
| Board Material | FR-4 glass epoxy, FR-4 high Tg, Rohs compliant,Aluminum,Rogers,etc. |
| Board Cutting | Shear,V-score,Tab-routed |
| Board Thickness | 0.2-7.0mm, Flex 0.01-0.25mm |
| Copper Weight | 1.0, 1.5, 2.0 oz |
| Solder Mask | Double-sided green LPI,Also support Red,White,Yellow,Blue,Black |
| Silk Screen Min Line Width | 0.003'' or 0.15mm |
| Min Drill Hole Diameter | 0.01'',0.25mm, or 10mils |
| Surface Finish | HASL,Nickle,ENIG,Immersion Tin,Immersion Silver,OSP,etc. |
| Board Thickness Tolerance | ±10% |
| Copper Weight Tolerance | ± 0.25 oz |
| Minimal Slot Width | 0.12'', 3.0mm, or 120mils |
| V-Score Depth | 20-25% of board thickness |
| Operating Temperature | -40°C ~ 105°C |
| Certificate | ISO9001/Iso14001/CE/ROHS |
| Design File Formate | Gerber RS-274,274D,Eagle and AutoCAD's DXF,DWG |
| Supply Ability | 10000000 Piece/Pieces per Month |
| Packaging Details | Vacuum, ESD, Carton |
Technical Specification For PCBA
|
SMT
| Position accuracy:20 um |
| Components size:0.4×0.2mm(01005) —130×79mm,Flip-CHIP,QFP,BGA,POP |
| Max. component height::25mm |
| Max. PCB size:680×500mm |
| Min. PCB size:no limited |
| PCB thickness:0.3 to 6mm |
| PCB weight:3KG |
| | Max. PCB width:450mm |
| Min. PCB width: no limited |
| Component height:Top 120mm/Bot 15mm |
|
Sweat-Solder
| Metal type :part, whole, inlay, sidestep |
| Metal material:Copper , Aluminum |
| Surface Finish:plating Au, plating sliver , plating Sn |
| | Air bladder rate:less than 20% |
| Press range:0-50KN |
| Max. PCB size:800X600mm |
| Testing | ICT,Probe flying,burn-in,function test,temperature cycling |
Product Packaging:
The EMS PCB Assembly product will be packaged securely in anti-static bags and placed in a sturdy cardboard box with protective foam inserts.
Shipping:
We offer worldwide shipping for the EMS PCB Assembly product. Shipping options include standard, expedited, and express delivery. Customers can choose their preferred shipping method during the checkout process.
All shipments will be tracked and customers will receive a tracking number once the product has been shipped. Shipping fees will be calculated at checkout based on the destination and selected shipping method.
FAQ:
Q1: What service do you have?
XHT: We provide turnkey solutions including PCB design, Software development, PCB Assembly, Enclosure design, Mold-making, Plastic injection, Finish product assembly, and function testing.
Q2: What are the main products of your PCB/PCBA services?
XHT: Our PCB/PCBA services are mainly for industries including Industrial control, Home appliances main boards, automotive electronics, Consumer electronics, Medical equipment, bank equipment, smart home, etc.
Q3: Is XHT a factory or trade company?
XHT: XHT is a 20-year experienced professional contract manufacturer to provides a stop Turnkey PCB assembly and electronics manufacturing service.
Q4: Can we inspect quality during production?
XHT: Yes, we are open and transparent on each production process with nothing to hide. Customers are welcome to inspect our production process and check in-house.
Q5: How can we ensure our information should not let the third party see our design?
XHT: We are willing to sign an NDA effect by customer side local law and promise to keep customers' data in high confidential level.
Q6: What files are required to get a quotation from you?
XHT: For OEM PCBA projects, please provide the Gerber data/files and an indication of related technical requirements as well as any special requirements if you have them; For ODM projects, please provide a Function List, so our engineering team can work on it.
Q7: What is the standard delivery term?
XHT: Delivery terms of EXW, FCA, FOB, DDU, etc. are all available based on each quote.
Q8: How long does it take for a PCBA quote?
XHT: Depends on the project's complexity. Normally 1-2 weeks is enough for our engineers to evaluate.
Q9: Do you have any minimum order quantity (MOQ) requirements?
XHT: No, we do not have MOQ requirements, we can support your projects starting from prototypes to mass productions.
Tell us your requirements about the FAQ by CLICKING HERE, so that we can provide a solution to save your budget and meet your needs!
